Water Pump : 67 lpm

Water Tank Capacity : 650 l and Hose 15 m

■ Smartstar Control

■ Color LCD

■ Diagnostic

■ Fuel Saving Mode

■ Remote Control (Hetronic)

Weight (Without Truck) : 4.645 kg

■ Hopper Vibrator

■ Hydraulic Driven Fan

■ Betonstar IoT System

■ Remote Control (HBC)

■ Air Compressor

■ High Pressure Cleaning Kit (140 bar)

Concrete Valve : S Valve System

Switch-Over Pressure S-Tube : 190 bar

Delivery Cylinders Diameter : 230 mm

Delivery Cylinders Lenght : 1000 mm

Hopper Capacity : 450 l

Hopper Outlet Diameter : 125 mm

Reducer Output Diameter : 150 mm

Switching System : Elect. Magn. Sensor

Lubrication System : Hydraulic (LINCOLN)

Driven by : PTO or Gear Box

Electric Box : Waterproof and PLC Controlled

Water Pump : 67 lpm

Water Tank Capacity : 650 lt and hose 15 m (172 gal and 49’3”)

■ Smartstar Control

■ Color LCD

■ Diagnostic

■ Fuel Saving Mode

■ Remote Control (Hetronic)

Weight(without truck) : 4560 kg (10052 lbs)

■ Hopper vibrator

■ Hydraulic driven fan

■ Betonstar IoT system

■ Remote control(HBC)

■ Air Compressor

■ High pressure cleaning kit (140 bar/2030 psi)

Concrete Valve : S valve system

Switch-over pressure S-tube : 190 bar (2756 psi)

Delivery cylinders diameter : 230 mm (9,05”)

Delivery cylinders stroke : 1000 mm (3’4”)

Hopper capacity : 450 lt (119 gal)

Hopper outlet diameter : 125 mm (4,9”)

Lateral output pipeline : 150 mm (5,9”)

Switching System : Elect. Magn. Sensor

Lubrication System : Hydraulic (LINCOLN)

Driven by : PTO or gearbox

Electric box : Waterproof and PLC controlled
