Water Pump : 67 lpm

Water Tank Capacity : 650 l and Hose 15 m

■ Smartstar Control

■ Color LCD

■ Diagnostic

■ Fuel Saving Mode

■ Remote Control (Hetronic)

Weight (Without Truck) : 11.840 kg

■ Hopper Vibrator

■ Hydraulic Driven Fan

■ Betonstar IoT System

■ Remote Control (HBC)

■ Air Compressor

■ High Pressure Cleaning Kit (140 bar)

Power : 265 kW (360 hp) (Diesel)

Concrete Valve : S Valve System

Switch-Over Pressure S-Tube : 190 bar

Delivery Cylinders Diameter : 200 mm

Delivery Cylinders Lenght : 2100 mm

Hopper Capacity : 650 l

Hopper Outlet Diameter : 125 mm

Reducer Output Diameter : 150 mm

Switching System : Elect. Magn. Sensor

Lubrication System : Hydraulic (LINCOLN)

Driven by : Engine

Electric Box : Waterproof and PLC Controlled

■ Smartstar Control

■ Color LCD

■ Diagnostic

■ Fuel Saving Mode

■ Remote Control (Hetronic)

Weight (Without Truck) : 14.995 kg (33.058 lb)

■ Hopper Vibrator

■ Hydraulic Driven Fan

■ Betonstar IoT System

■ Remote Control (HBC)

■ Air Compressor

■ High Pressure Cleaning Kit (135 bar / 1958 psi)

■ Water Pump (67 lpm) (17,7 gpm)

■ Water Tank Capacity ( 650 l (171,71 gal) and Hose 15 m (49’2’’) )

Power : 265 kW (355 hp) (Diesel)

Concrete Valve : S Valve System

Switch-Over Pressure S-Tube : 190 bar (2755,7 psi)

Delivery Cylinders Diameter : 200 mm (7,87”)

Delivery Cylinders Stroke : 2100 mm (6’,9’’)

Hopper Capacity : 650 l (171,71 gal)

Hopper Outlet Diameter : 125 mm (5,5”)

Lateral Output Pipeline : 150 mm (6”)

Switching System : Elect. Magn. Sensor

Lubrication System : Hydraulic (LINCOLN)

Driven by :  Engine

Electric Box : Waterproof and PLC Controlled
