Concrete Valve : S Valve System

Switch-Over Pressure S-Tube : 190 bar

Delivery Cylinders Diameter : 200 mm

Delivery Cylinders Lenght : 1400 mm

Hopper Capacity : 650 l

Hopper Outlet Diameter : 125 mm

Reducer Output Diameter : 150 mm

Switching System : Elect. Magn. Sensor

Lubrication System : Hydraulic (LINCOLN)

Electric Box : Waterproof and PLC Controlled

■ Hopper Vibrator

■ Hydraulic Driven Fan

■ Betonstar IoT System

■ Remote Control (HBC)

■ Air Compressor

■ High Pressure Cleaning Kit (140 bar)

■ Water Pump (67 lpm)

■ Water Tank (500 l and Hose 15 m)

Engine* : 160 kW (214 hp) (Diesel)

■ Smartstar Control

■ Color LCD

■ Diagnostic

■ Fuel Saving Mode

■ Remote Control

Weight: : 4.750 kg

Weight: : 5250 (11574 lbs)

■ Hopper Vibrator

■ Hydraulic Driven Fan

■ Betonstar IoT System

■ Air Compressor

■ High Pressure Cleaning Kit (160 bar / 2320 psi)

■ Water Pump (67 lpm) (17.7 gpm)

■ Water Tank (500 l (132 gal) and Hose 15 m (49’2’’) )

Engine* : 160 kW (214 hp) (Diesel)

■ Smartstar Control

■ Color LCD

■ Diagnostic

■ Fuel Saving Mode

■ Remote Control

Concrete Valve : S Valve System

Switch-Over Pressure S-Tube : 190 bar (2755,7 psi)

Delivery Cylinders Diameter : 200 mm (7,87”)

Delivery Cylinders Stroke : 1400 mm (55,11”)

Hopper Capacity : 650 l (171,71 gal)

Hopper Outlet Diameter : 125 mm (4,92”)

Lateral Output Pipeline : 150 mm (5,9”)

Switching System : Elect. Magn. Sensor

Lubrication System : Electrically Controlled Central System  (LINCOLN)

Electric Box : IP65 PLC Controlled
