Rod Side |
Theo. Conc. Output (max) |
: 90 m³/h |
|
Theo. Conc. Pressure (max) |
: 71 bar |
|
|
Stroke |
: 34 Stroke / min |
|
|
Piston Side |
Theo. Conc. Output (max) |
: 61 m³/h |
|
Theo. Conc. Pressure (max) |
: 106 bar |
|
|
Stroke |
: 23 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 200 mm
Delivery Cylinders Lenght : 1400 mm
Hopper Capacity : 650 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Remote Control (HBC)
■ Air Compressor
■ High Pressure Cleaning Kit (140 bar)
■ Water Pump (67 lpm)
■ Water Tank (500 l and Hose 15 m)
Engine* : 110 kW (150 hp) (Electric)
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control
Weight: : 4.800 kg
