Weight: : 7.500 kg
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control
Engine* : 265 kW (350 hp) (Diesel)
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Remote Control (HBC)
■ Air Compressor
■ High Pressure Cleaning Kit (140 bar)
■ Water Pump (67 lpm)
■ Water Tank (500 l and Hose 15 m)
Max. hydraulic pressure : | 350 bar (5076,32 psi) |
Rod Side |
Theo. Conc. Output (max) |
: 90 m³/h |
Theo. Conc. Pressure (max) |
: 92 bar |
|
Stroke |
: 23 Stroke / min |
|
Piston Side |
Theo. Conc. Output (max) |
: 56 m³/h |
Theo. Conc. Pressure (max) |
: 150 bar |
|
Stroke |
: 14 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 200 mm
Delivery Cylinders Lenght : 2100 mm
Hopper Capacity : 650 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
