Weight: : 8.750 kg
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control
Engine* : 160 kW (290 hp) (Electric)
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Remote Control (HBC)
■ Air Compressor
■ High Pressure Cleaning Kit (140 bar)
■ Water Pump (67 lpm)
■ Water Tank (500 l and Hose 15 m)
|
Rod Side |
Theo. Conc. Output (max) |
: 90 m³/h |
|
Theo. Conc. Pressure (max) |
: 92 bar |
|
|
Stroke |
: 23 Stroke / min |
|
|
Piston Side |
Theo. Conc. Output (max) |
: 56 m³/h |
|
Theo. Conc. Pressure (max) |
: 150 bar |
|
|
Stroke |
: 14 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 200 mm
Delivery Cylinders Lenght : 2100 mm
Hopper Capacity : 650 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
Weight: 6200 kg (13670 lb)
■ Smartstar Control
■ Color LCD
■ Diagnostic
■ Fuel Saving Mode
■ Remote Control
Engine* : 160 kW (214 hp) (Electric)
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Betonstar IoT System
■ Air Compressor
■ High Pressure Cleaning Kit (160 bar / 2320 psi)
■ Water Pump (67 lpm) (17,7 gpm)
■ Water Tank (500lt (132 gal) and Hose 15 m (49'2''))
|
Rod Side |
Theo. Conc. Output (max) |
: 90 m³/h (117,7 yd³ / h) |
|
Theo. Conc. Pressure (max) |
: 92 bar (1334 psi) |
|
|
Stroke |
: 23 Stroke / min |
|
|
Piston Side |
Theo. Conc. Output (max) |
: 56 m³/h (73,24 yd³ / h) |
|
Theo. Conc. Pressure (max) |
: 150 bar (2175 psi) |
|
|
Stroke |
: 14 Stroke / min |
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar (2755,7 psi)
Delivery Cylinders Diameter : 200 mm (7,87”)
Delivery Cylinders Stroke : 2100 mm (6’,10'')
Hopper Capacity : 650 l (171,71 gal)
Hopper Outlet Diameter : 125 mm (4,92”)
Lateral Output Pipeline : 150 mm (5,9”)
Switching System : Elect. Magn. Sensor
Lubrication System : Electrically Controlled Central System (LINCOLN)
Electric Box : IP65 PLC Controlled
