| Pump Group | BST 31.14H 5Z (OPT.) | BST 31.16 5Z (STD.) |
| Theo. Conc. Output (max) (Rod Side) |
140 m³ / h (183,11 yd³ / h) |
160 m³ / h (209,27 yd³ / h) |
| Theo. Conc. Pressure (max) (Rod Side) |
85 bar (1232,82 psi) |
85 bar (1232,82 psi) |
| Stroke | 26 Stroke / min | 26 Stroke / min |
| Concrete Cylinder Dimensions |
230 mm x 2100 mm (9,05" x 82,68") |
250 mm x 2100 mm (9,84" x 82,68") |
Hopper Capacity : 650 l (171,71 gal)
Switching System : Electromagnetic Sensor
Concrete Valve : S Valve System
Electric Box : IP65 PLC Controlled
Remote Control : HBC Remote Control
End Hose : 3 m (9' 10") 4" Diameter
Water Pump : 67 lpm (17,7 gpm)
Water Tank Capacity : 650 l (171 gal) and Hose 15 m (49' 2")
Lubrication System : Electrically Controlled Central System (LINCOLN)
Driven by : Gear Box (Stiebel)
Boom Type : Z
Sections : 5
Boom Swing Time : 114 sec
Boom Swinging Angle : 365°
Concrete Pipe Diameter : 125 mm (4,92’’)
Front Legs : X
Rear Legs : Sliding Support
■ Smartstar Control
■ Color LCD
■ IP69K Electronic Keypad
■ Diagnostic
■ Fuel Saving Mode
■ 2nd Back up Radio Remote and Receiver
■ Hopper Vibrator
■ Hydraulic Driven Fan
■ Stability Control
■ Air Compressor
■ End Hose Squeeze Valve
■ High Pressure Cleaning Kit (160 bar / 2320 psi)
■ Betonstar IoT System
■ Tool Boxes (If space is available)
■ Water and Oil Tank Heater
